| Wheel base (mm) | 4500 | |||
| Dimensions (mm) | 8620X2500X3260 | |||
| Curb weight （kg） | 7950 | |||
| Front overhang/rear overhang (mm) | 1410/2216 | |||
| Approach angle/Departure angle | 26/25 | |||
| Min. Ground clearance (mm) | 500 | |||
| Max speed (km/h) | 90 | |||
| Engine (WEICHAI) | Model | WD615.56，water-cooled，four strokes，6 cylinders straight in line，turbocharged, | ||
| Fuel type | Diesel | |||
| Min rate of consuming fuel（g/(kw.h)） |
198g/kw.h |
|||
| Rated Power / rotating
（kw/(r/min) |
193Kw（270HP）/2200rpm |
|||
| Emission | EURO II | |||
| Maximum Torque / rotating speed（n.m/(r/min) | 1100Nm/1300-1600rpm | |||
| Displacement（ml） | 9726 | |||
| Fuel tanker capacity （L） | 400L Iron | |||
| Clutch | Model | #430, Single dry frictional disc，Hydraulic boosting | ||
| Gearbox(Fuller) | Model |
9JS135B mechanical type，mechanical type，Based on Fuller Eaton technology ,9 Forward speed gear, 1 Reserve gear
|
||
| P.T.O | Model | QH50 | ||
| Brake system
|
Service brake | Brake gap can be adjusted automatically, double circulation air brake system | ||
| Assistant brake
|
Engine exhaust brake | |||
| Park brake | Potential springs pressing on rear wheels | |||
| Steering system
|
Model | ZF8098, whole circulation in ball type, hydraulic boosting ZF Technology | ||
| Suspension System
|
Frount & Rear Suspension
|
Non-free standing stabilization spring， stabilization suspension，
Front 13 springs, Rear 8+6 springs |
||
| Frame | Fish belly shape, variable width, variable sections
Based on Germany Benz Technology
|
|||
| Dimison | 317X70X8.5+7mm | |||
| Front axle (Mercedes Benz Technology) | Double-shoe pneumatic brake, 7.5tons no-driving steering axle | |||
| Rear axle (Mercedes Benz Technology)
|
Double-shoe pneumatic brake, ductile casting casing, with hub redactor, 13 tons double reduction driving axle,speed ratio 5.263 | |||
| Tire model | 12.00R20 radial tire | |||
| Qty of tire | 7（6+1） 1 spare tire | |||
| Electrical system
|
Battery
|
2X12V/135Ah | ||
| Generator | 28V-70A | |||
| Starter
|
5.4Kw/24V | |||
| Cab | NG80B (Benz technology)
Right hand Drive Short cab with no sleeper Full steel skeleton structure, covered with double layer steel plate; Can be tipped forwardly;
|
|||
|
Interior trimming: Integral interior trimming, Integral instrument, digital instrument, radio (with USB interface+MP3), high back/shock absorption seat for driver, high back seat for co-driver. Steering wheel can be adjusted. With inner A/C。
|
||||
| Exterior trimming:
Metal bumper, three steps, new mirror, outside sun visor |
||||
Sewerage Truck (4×2)
Mobile: 01771122083 / 01519600000 / 01732646163
