Product Description
120A 200A 300A 400A 1-150mm steel cutter Gantry CNC Plasma Cutting Machine China CNC Plasma Metal Cutting Machine Plasma Cut Machine price
Applicable Industries
Ship Building,Construction Equipment,Transport Equipment,Aerospace Industry,Bridge Building, Military Industrial,Wind Power,Structural Steel,Boiler Containers,Agriculture Machinery,Chassis Electrical Cabinets,Elevator Manufacturers,Textile Machinery,
Environmental ProtectionEquipment,Ect.
Applicable Materials
Aluminum,Copper,Titanium,Nickel,Iron,Galvanized Sheet,White Steel,Titanium Plate,Carbon
Steel,Stainless Steel,Alloy Steel,
Composite Metal
This serials CNC equipment is aimed at metal plate, tube materials baiting, not only the appearance of atmospheric but also stable operating, high working efficency, long service life and it can be achieved cutting all kinds of design graphic.
Applicable Industries
Ship Building,Construction Equipment,Transport Equipment,Aerospace Industry,Bridge Building, Military Industrial,Wind Power,Structural Steel,Boiler Containers,Agriculture Machinery,Chassis Electrical Cabinets,Elevator Manufacturers,Textile Machinery,Environmental Protection Equipment,Ect.
Gantry plasma flame cutting machine parameter:
| Model | BLDH-3060 | BLDH-4080 | BLDH-5080 | BLDH-60100 | BLDH-80100 |
| Track gauge(mm) | 3000 | 4035 | 5000 | 6000 | 8000 |
| Effective cutting width(mm) | 2300 | 3300 | 4300 | 5300 | 7300 |
| Machine width(mm) | 3500 | 4300 | 5500 | 6500 | 8500 |
| Track length(mm) | 6000 | 8000 | 8000 | 10000 | 10000 |
| Number of standard cutting torch(set) | 1 | 2 | 2 | 2 | 2 |
| Input power | AC380V/50Hz;AC220V/50Hz | ||||
| Lift(mm) | 200 | ||||
| Cutting thickness(mm) | Flame cutting:5-150 Plasma cutting:1-30(According to the power supply size) | ||||
| Cutting speed (mm/min) | Flame cutting:100-1000 Plasma cutting:450-5000 | ||||
| Idle speed | 0-8000 | ||||
| Drive mode | Bilateral drive | ||||
| System | Shanghai Fangling or Beijing Starfire | ||||
| Operating accurancy | ±0.5mm | ||||
